Large Diaphragm Condenser Studio Microphone
ME-500
ME-500 is a high quality large diaphragm classical condenser microphone with a cardioid pickup pattern. Utilising FET as preamp. this microphone has perfect sound and low noise.
By combining excellent circuit and ideal housing design, this microphone has a high sensitivity,wide dynamic range and frequency response, especially suitable for stage performance.studio, personal film making and many other similar situations.
By combining excellent circuit and ideal housing design, this microphone has a high sensitivity,wide dynamic range and frequency response, especially suitable for stage performance.studio, personal film making and many other similar situations.
Quantity
We offer OEM &ODM services.
—————————————————————
Element: Ø34mm Pressure Gradient Transducer
Polar Pattern: Cardioid
Frequency Response: 20Hz~20KHz
Sensitivity: -34dB±2dB(0dB=1 V/Pa at 1kHz)
Output Impedance: 200Ω±30%（at 1kHz）
Load Impedance: ≥1000Ω
Self Noise: 14dB A
Max.Input SPL: 135dB(at 1kHz≤1%T.H.D)
S/N Ratio: 80dB
Power Requirement: 48V Phantom Power
Current Consumption: 3.2mA
Body Dimensions: Ø56x185mm
—————————————————————
Element: Ø34mm Pressure Gradient Transducer
Polar Pattern: Cardioid
Frequency Response: 20Hz~20KHz
Sensitivity: -34dB±2dB(0dB=1 V/Pa at 1kHz)
Output Impedance: 200Ω±30%（at 1kHz）
Load Impedance: ≥1000Ω
Self Noise: 14dB A
Max.Input SPL: 135dB(at 1kHz≤1%T.H.D)
S/N Ratio: 80dB
Power Requirement: 48V Phantom Power
Current Consumption: 3.2mA
Body Dimensions: Ø56x185mm
