Large Diaphragm Condenser Studio Microphone

Ribbon Microphone,microphone ribbon microphone,microphone ribbon,ribbon microphone,microphone,recording microphone,Ribbon Microphone RM9| AYM AUDIO,microphone ribbon microphone,microphone ribbon, recording microphone,RM9 is a classical ribbon recording microphone which has a unique appearance, it utilises the exact complete electronic circuit design,with-10db attenuation and low cut switch on the body, the microphone has high sensitivity, low noise, no distortion, wide frequency response, fast transient response.,Ribbon Microphone,ribbon microphone,microphone ribbon microphone,microphone ribbon,microphone,Ribbon Microphone RM5 | AYM AUDIO,ribbon microphone,microphone,recording microphone,RM5 is a classical ribbon recording microphone, which utilises pure aluminum foil with 62mmlength and 0002mm thickness. With vivid and nature sound and fast transient response.

Model NO. ME-500

ME-500 is a high quality large diaphragm classical condenser microphone with a cardioid pickup pattern. Utilising FET as preamp. this microphone has perfect sound and low noise.
By combining excellent circuit and ideal housing design, this microphone has a high sensitivity,wide dynamic range and frequency response, especially suitable for stage performance.studio, personal film making and many other similar situations.

Quantity

We offer OEM &ODM services.
—————————————————————
Element: Ø34mm Pressure Gradient Transducer
Polar Pattern: Cardioid
Frequency Response: 20Hz~20KHz
Sensitivity: -34dB±2dB(0dB=1 V/Pa at 1kHz)
Output Impedance: 200Ω±30%（at 1kHz）
Load Impedance: ≥1000Ω
Self Noise: 14dB A
Max.Input SPL: 135dB(at 1kHz≤1%T.H.D)
S/N Ratio: 80dB
Power Requirement: 48V Phantom Power
Current Consumption: 3.2mA
Body Dimensions: Ø56x185mm
